38 Meter Telescopic Boom Lift
38 Meter Telescopic Boom Lift
The JLG 1250SJP – 38 Meter Telescopic Boom Lift is a high-performance aerial platform designed for extreme reach and elevated workspaces. With a maximum working height of 38.73 meters and an impressive horizontal outreach of 22.86 meters, it offers exceptional versatility and strength. Its dual-capacity platform supports up to 450 kg (restricted), making it ideal for heavy-duty applications in construction, maintenance, and industrial operations.
Features
| Brand & Model No | JLG 1250SJP |
| Maximum Working Height | 38.73 m |
| Platform Height | 36.73 m |
| Horizontal Outreach | 22.86 m |
| Working Outreach | 23.51 m |
| Platform Capacity (Restricted) | 450 kg |
| Platform Capacity (Unrestricted) | 230 kg |
| Platform Rotator | 180° Hydraulic |
| Jib Length | 2.44 m |
| Jib Articulation | 130° Vertical (+75° / -55°) |
| Jib PLUS® Articulation | 180° Horizontal |
| Platform Size | 0.91 m x 2.44 m |
| Overall Width (Axles Retracted / Extended) | 2.49 m / 3.81 m |
| Tail Swing (Working Condition) | 1.68 m |
| Stowed Height | 3.05 m |
| Stowed Length | 13.67 m |
| Transport Length | 10.64 m |
| Wheelbase | 3.81 m |
| Ground Clearance | 0.30 m |
| Machine Weight | 18,650 kg |
| Maximum Ground Bearing Pressure | 7.03 kg/cm² |
| Drive Speed | 5.2 km/h |
| Gradeability | 45% |
| Axle Oscillation | 0.30 m |
| Turning Radius (Inside – Axles Retracted) | 4.39 m |
| Turning Radius (Outside – Axles Retracted / Extended) | 6.86 m / 5.89 m |
