The JCB 541-70 is a hugely productive full-sized DIESELMAX-powered telescopic handler. It’s powerful, efficient, manoeuvrable, comfortable and safe.

Brand – Model:

 JCB 541-70

Overall height: 2.49 M
Overall width (over tyres)*: 2.23 M
Inside width of cab:

0.94 M

Front track: 1.81 M
Wheelbase: 2.75 M
Overall length to front tyres: 4.38 M
Overall length to front carriage: 4.99 M
Ground clearance: 0.40 M
Front wheel centre to carriage: 1.25 M
Rear wheel centre to rear face: 0.99 M
Weight: 7850 KG

View Document

JCB 541-70



The JCB 541-70 Loadall is a powerful and efficient telescopic handler. Its 74.2kW JCB DIESELMAX engine sits on a chassis that’s specially designed to provide the ultimate load-bearing and stability.

The side-mounted engine combines with JCB axles and transmission to ensure a reliable drivetrain performance from well-proven components.

Then there’s instant steering selection between three modes for easy operation, a tight turn radius and great manoeuvrability.

  • 82 l/min max hydraulic flow
  • High power and torque at low revs
  • Mechanical joystick, direct acting hydraulic control levers
